"Cablu incendiu JEH(St)H...Bd FE180 PH120 2x2x0.8 mm+0.8 , rezistenta la foc 120 minute, compatibilitate E30/E90producator 2M Kablo, 3T00000109-100Diametru fir: 0.8mmConductor: perechi torsadate cu protectie din fibra de sticla, cupru 100%Culori fire: con

"<br /> Cablu incendiu JEH(St)H...Bd FE180 PH120 2x2x0.8 mm+0.8 , rezistenta la foc 120 minute, compatibilitate E30/E90<br /> producator 2M Kablo, 3T00000109-100<br /> Diametru fir: 0.8mm<br /> Conductor: perechi torsadate cu protectie din fibra de sticla, cupru 100%<br /> Culori fire: conform -VDE0815<br /> Manta: Halogen free, si rezistenta la flacara, culoare portocaliu (RAL2004Orange), Fire ResistantSilicon Rubber (EN 50363-1, BS7655EI2)<br /> Ambalare: tambur 100metri<br /> OperatingVoltage 300V<br /> Flame Retardancy IEC/EN 60332-1, IEC/EN 60332-3-24<br /> Fire Resistance IEC60331-21,EN 50200 (PH120)<br /> Smoke Density IEC/EN 61034-1/2<br /> CorrosiveGases Measurement IEC/EN 60754-1/2<br /> Min. Bending Radius: 10x cable diameter<br /> Conductor Resistance 0.80mm - ≤36.6 Ω/km;1.00 mm - ≤22.2 Ω/km;1.50 mm²- ≤12.1 Ω/km"

Identificare produs

• Brand: 2MKABLO
• Categorie: Accesorii
• SKU: 3T00000109-1-100
• EAN / GTIN: 3000001091100
• Garanție: 24 luni

Specificații

• "<br /> Cablu incendiu JEH(St)H...Bd FE180 PH120 2x2x0.8 mm+0.8
• rezistenta la foc 120 minute
• compatibilitate E30/E90<br /> producator 2M Kablo
• 3T00000109-100<br /> Diametru fir: 0.8mm<br /> Conductor: perechi torsadate cu protectie din fibra de sticla
• cupru 100%<br /> Culori fire: conform -VDE0815<br /> Manta: Halogen free
• si rezistenta la flacara
• culoare portocaliu (RAL2004Orange)
• Fire ResistantSilicon Rubber (EN 50363-1
• BS7655EI2)<br /> Ambalare: tambur 100metri<br /> OperatingVoltage 300V<br /> Flame Retardancy IEC/EN 60332-1
• IEC/EN 60332-3-24<br /> Fire Resistance IEC60331-21
• EN 50200 (PH120)<br /> Smoke Density IEC/EN 61034-1/2<br /> CorrosiveGases Measurement IEC/EN 60754-1/2<br /> Min. Bending Radius: 10x cable diameter<br /> Conductor Resistance 0.80mm - ≤36.6 Ω/km
• 1.00 mm - ≤22.2 Ω/km
• 1.50 mm²- ≤12.1 Ω/km"
